Description
FIXED IND 27UH 100MA 4.7 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 0819-58J.
0819-58J has an inductance value of 27 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
0819-58J is rated for 100 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
0819-58J lists a DC resistance of 4.7Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
0819-58J uses a package or case of Through Hole. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 0819-58J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 27 µH |
| Tolerance | ±5% |
| Current Rating | 100 mA |
| DC Resistance (DCR) | 4.7Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | - |
| Case / Size | Through Hole |
| Package / Case | Through Hole |
| Supplier | Delevan |
| Description | FIXED IND 27UH 100MA 4.7 OHM TH |
| Series | 819 |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 45 @ 2.5MHz |
| Self Resonant Frequency | 17MHz |
| Ratings | - |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | - |
| Supplier Device Package | Axial |
| Height - Seated (Max) | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) |
| Features | - |
