Description
FIXED IND 1.8UH 457MA 720 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1008-182H.
1008-182H has an inductance value of 1.8 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1008-182H is rated for 457 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1008-182H lists a DC resistance of 720mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1008-182H uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1008-182H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.8 µH |
| Tolerance | ±3% |
| Current Rating | 457 mA |
| DC Resistance (DCR) | 720mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.105" L x 0.095" W (2.66mm x 2.41mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Delevan |
| Description | FIXED IND 1.8UH 457MA 720 MOHM |
| Series | 1008 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 7.9MHz |
| Self Resonant Frequency | 76MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.085" (2.16mm) |
