Description
FIXED IND 220NH 1.055A 135 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1008-221H.
1008-221H has an inductance value of 220 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1008-221H is rated for 1.055 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1008-221H lists a DC resistance of 135mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1008-221H uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1008-221H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 220 nH |
| Tolerance | ±3% |
| Current Rating | 1.055 A |
| DC Resistance (DCR) | 135mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.105" L x 0.095" W (2.66mm x 2.41mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Delevan |
| Description | FIXED IND 220NH 1.055A 135 MOHM |
| Series | 1008 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 25MHz |
| Self Resonant Frequency | 450MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.085" (2.16mm) |
