Description
FIXED IND 2.7UH 413MA 880 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1008-272H.
1008-272H has an inductance value of 2.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1008-272H is rated for 413 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1008-272H lists a DC resistance of 880mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1008-272H uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1008-272H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 2.7 µH |
| Tolerance | ±3% |
| Current Rating | 413 mA |
| DC Resistance (DCR) | 880mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.105" L x 0.095" W (2.66mm x 2.41mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Delevan |
| Description | FIXED IND 2.7UH 413MA 880 MOHM |
| Series | 1008 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 7.9MHz |
| Self Resonant Frequency | 62MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.085" (2.16mm) |
