Description
FIXED IND 27UH 146MA 7 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1008-273H.
1008-273H has an inductance value of 27 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1008-273H is rated for 146 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1008-273H lists a DC resistance of 7Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1008-273H uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1008-273H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 27 µH |
| Tolerance | ±3% |
| Current Rating | 146 mA |
| DC Resistance (DCR) | 7Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.105" L x 0.095" W (2.66mm x 2.41mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Delevan |
| Description | FIXED IND 27UH 146MA 7 OHM SMD |
| Series | 1008 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 2.5MHz |
| Self Resonant Frequency | 15MHz |
| Ratings | - |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.085" (2.16mm) |
