Description
FIXED IND 3.9UH 354MA 1.2 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1008-392H.
1008-392H has an inductance value of 3.9 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1008-392H is rated for 354 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1008-392H lists a DC resistance of 1.2Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1008-392H uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1008-392H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.9 µH |
| Tolerance | ±3% |
| Current Rating | 354 mA |
| DC Resistance (DCR) | 1.2Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.105" L x 0.095" W (2.66mm x 2.41mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Delevan |
| Description | FIXED IND 3.9UH 354MA 1.2 OHM |
| Series | 1008 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 7.9MHz |
| Self Resonant Frequency | 57MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.085" (2.16mm) |
