Description
FIXED IND 270NH 759MA 360 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1210R-271K.
1210R-271K has an inductance value of 270 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1210R-271K is rated for 759 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1210R-271K lists a DC resistance of 360mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1210R-271K uses a package or case of 1210 (3225 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1210R-271K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 270 nH |
| Tolerance | ±10% |
| Current Rating | 759 mA |
| DC Resistance (DCR) | 360mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.128" L x 0.095" W (3.25mm x 2.42mm) |
| Case / Size | 1210 (3225 Metric) |
| Package / Case | 1210 (3225 Metric) |
| Supplier | Delevan |
| Description | FIXED IND 270NH 759MA 360 MOHM |
| Series | 1210R |
| Product Status | Active |
| Core Material | Iron |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 25MHz |
| Self Resonant Frequency | 320MHz |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1210 |
| Height - Seated (Max) | 0.101" (2.57mm) |
