Description
FIXED IND 680NH 588MA 600 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1210R-681F.
1210R-681F has an inductance value of 680 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1210R-681F is rated for 588 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1210R-681F lists a DC resistance of 600mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1210R-681F uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1210R-681F to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 680 nH |
| Tolerance | ±1% |
| Current Rating | 588 mA |
| DC Resistance (DCR) | 600mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.128" L x 0.095" W (3.26mm x 2.41mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 680NH 588MA 600 MOHM |
| Series | 1210R |
| Product Status | Active |
| Core Material | Iron |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 25MHz |
| Self Resonant Frequency | 160MHz |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.101" (2.57mm) |
