Description
FIXED IND 820NH 556MA 670 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1210R-821F.
1210R-821F has an inductance value of 820 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1210R-821F is rated for 556 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1210R-821F lists a DC resistance of 670mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1210R-821F uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1210R-821F to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 820 nH |
| Tolerance | ±1% |
| Current Rating | 556 mA |
| DC Resistance (DCR) | 670mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.128" L x 0.095" W (3.26mm x 2.41mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 820NH 556MA 670 MOHM |
| Series | 1210R |
| Product Status | Active |
| Core Material | Iron |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 25MHz |
| Self Resonant Frequency | 140MHz |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.101" (2.57mm) |
