Description
FIXED IND 470NH 660MA 350 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1330-12H.
1330-12H has an inductance value of 470 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1330-12H is rated for 660 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1330-12H lists a DC resistance of 350mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1330-12H uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1330-12H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 470 nH |
| Tolerance | ±3% |
| Current Rating | 660 mA |
| DC Resistance (DCR) | 350mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.313" L x 0.115" W (7.95mm x 2.92mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 470NH 660MA 350 MOHM |
| Series | 1330 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Phenolic |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 25MHz |
| Self Resonant Frequency | 330MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.145" (3.68mm) |
