Description
FIXED IND 560NH 550MA 500 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1330-14H.
1330-14H has an inductance value of 560 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1330-14H is rated for 550 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1330-14H lists a DC resistance of 500mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1330-14H uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1330-14H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 560 nH |
| Tolerance | ±3% |
| Current Rating | 550 mA |
| DC Resistance (DCR) | 500mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.313" L x 0.115" W (7.95mm x 2.92mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 560NH 550MA 500 MOHM |
| Series | 1330 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Phenolic |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 25MHz |
| Self Resonant Frequency | 300MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.145" (3.68mm) |
