Description
FIXED IND 100UH 84MA 8 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1330R-68H.
1330R-68H has an inductance value of 100 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1330R-68H is rated for 84 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1330R-68H lists a DC resistance of 8Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1330R-68H uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1330R-68H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 100 µH |
| Tolerance | ±3% |
| Current Rating | 84 mA |
| DC Resistance (DCR) | 8Ohm Max |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.313" L x 0.115" W (7.95mm x 2.92mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 100UH 84MA 8 OHM SMD |
| Series | 1330R |
| Product Status | Active |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 35 @ 2.5MHz |
| Self Resonant Frequency | 13MHz |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.145" (3.68mm) |
