Description
FIXED IND 270NH 1.025A 120 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 160-271KS.
160-271KS has an inductance value of 270 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
160-271KS is rated for 1.025 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
160-271KS lists a DC resistance of 120mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
160-271KS uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 160-271KS to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 270 nH |
| Tolerance | ±10% |
| Current Rating | 1.025 A |
| DC Resistance (DCR) | 120mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.150" L x 0.120" W (3.81mm x 3.05mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Delevan |
| Description | FIXED IND 270NH 1.025A 120 MOHM |
| Series | 160 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Iron |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 25MHz |
| Self Resonant Frequency | 290MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.080" (2.03mm) |
