Description
FIXED IND 150UH 80MA 18 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 160R-154JS.
160R-154JS has an inductance value of 150 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
160R-154JS is rated for 80 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
160R-154JS lists a DC resistance of 18Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
160R-154JS uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 160R-154JS to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 150 µH |
| Tolerance | ±5% |
| Current Rating | 80 mA |
| DC Resistance (DCR) | 18Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.150" L x 0.120" W (3.81mm x 3.05mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 150UH 80MA 18 OHM SMD |
| Series | 160R |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 32 @ 790kHz |
| Self Resonant Frequency | 5.6MHz |
| Ratings | - |
| Inductance Test Frequency | 790 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.080" (2.03mm) |
