Description
FIXED IND 22UH 150MA 5.5 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 160R-223JS.
160R-223JS has an inductance value of 22 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
160R-223JS is rated for 150 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
160R-223JS lists a DC resistance of 5.5Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
160R-223JS uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 160R-223JS to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 22 µH |
| Tolerance | ±5% |
| Current Rating | 150 mA |
| DC Resistance (DCR) | 5.5Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.150" L x 0.120" W (3.81mm x 3.05mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 22UH 150MA 5.5 OHM SMD |
| Series | 160R |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Iron |
| Shielding | Unshielded |
| Q @ Frequency | 47 @ 2.5MHz |
| Self Resonant Frequency | 18MHz |
| Ratings | - |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.080" (2.03mm) |
