Description
FIXED IND 150UH 149MA 9 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1812-154G.
1812-154G has an inductance value of 150 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1812-154G is rated for 149 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1812-154G lists a DC resistance of 9Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1812-154G uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1812-154G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 150 µH |
| Tolerance | ±2% |
| Current Rating | 149 mA |
| DC Resistance (DCR) | 9Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.126" L x 0.126" W (3.20mm x 3.20mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 150UH 149MA 9 OHM SMD |
| Series | 1812 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 790kHz |
| Self Resonant Frequency | 6MHz |
| Ratings | - |
| Inductance Test Frequency | 790 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.190" (4.83mm) |
