Description
FIXED IND 220UH 142MA 10 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1812-224G.
1812-224G has an inductance value of 220 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1812-224G is rated for 142 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1812-224G lists a DC resistance of 10Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1812-224G uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1812-224G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 220 µH |
| Tolerance | ±2% |
| Current Rating | 142 mA |
| DC Resistance (DCR) | 10Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.126" L x 0.126" W (3.20mm x 3.20mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 220UH 142MA 10 OHM SMD |
| Series | 1812 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 790kHz |
| Self Resonant Frequency | 4MHz |
| Ratings | - |
| Inductance Test Frequency | 790 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.190" (4.83mm) |
