Description
FIXED IND 2.7UH 517MA 750 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1812-272G.
1812-272G has an inductance value of 2.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1812-272G is rated for 517 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1812-272G lists a DC resistance of 750mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1812-272G uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1812-272G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 2.7 µH |
| Tolerance | ±2% |
| Current Rating | 517 mA |
| DC Resistance (DCR) | 750mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.126" L x 0.126" W (3.20mm x 3.20mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 2.7UH 517MA 750 MOHM |
| Series | 1812 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 7.9MHz |
| Self Resonant Frequency | 50MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.190" (4.83mm) |
