Description
FIXED IND 33UH 224MA 4 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1812-333G.
1812-333G has an inductance value of 33 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1812-333G is rated for 224 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1812-333G lists a DC resistance of 4Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1812-333G uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1812-333G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 µH |
| Tolerance | ±2% |
| Current Rating | 224 mA |
| DC Resistance (DCR) | 4Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.126" L x 0.126" W (3.20mm x 3.20mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 33UH 224MA 4 OHM SMD |
| Series | 1812 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 2.5MHz |
| Self Resonant Frequency | 11MHz |
| Ratings | - |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.190" (4.83mm) |
