Description
FIXED IND 680NH 475MA 210 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 2510-20G.
2510-20G has an inductance value of 680 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
2510-20G is rated for 475 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
2510-20G lists a DC resistance of 210mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
2510-20G uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 2510-20G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 680 nH |
| Tolerance | ±2% |
| Current Rating | 475 mA |
| DC Resistance (DCR) | 210mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.255" L x 0.105" W (6.48mm x 2.67mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 680NH 475MA 210 MOHM |
| Series | 2510 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Iron |
| Shielding | Unshielded |
| Q @ Frequency | 35 @ 25MHz |
| Self Resonant Frequency | 210MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.110" (2.79mm) |
