Description
FIXED IND 1.2UH 385MA 320 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 2510-26G.
2510-26G has an inductance value of 1.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
2510-26G is rated for 385 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
2510-26G lists a DC resistance of 320mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
2510-26G uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 2510-26G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.2 µH |
| Tolerance | ±2% |
| Current Rating | 385 mA |
| DC Resistance (DCR) | 320mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.255" L x 0.105" W (6.48mm x 2.67mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 1.2UH 385MA 320 MOHM |
| Series | 2510 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Iron |
| Shielding | Unshielded |
| Q @ Frequency | 25 @ 7.9MHz |
| Self Resonant Frequency | 160MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.110" (2.79mm) |
