Description
FIXED IND 270NH 410MA 720 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 4232-271F.
4232-271F has an inductance value of 270 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
4232-271F is rated for 410 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
4232-271F lists a DC resistance of 720mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
4232-271F uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 4232-271F to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 270 nH |
| Tolerance | ±1% |
| Current Rating | 410 mA |
| DC Resistance (DCR) | 720mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.138" L x 0.105" W (3.51mm x 2.67mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 270NH 410MA 720 MOHM |
| Series | 4232 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Phenolic |
| Shielding | Unshielded |
| Q @ Frequency | 17 @ 25MHz |
| Self Resonant Frequency | 120MHz |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.101" (2.57mm) |
