Description
FIXED IND 1UH 650MA 90 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 4379-102KS.
4379-102KS has an inductance value of 1 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
4379-102KS is rated for 650 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
4379-102KS lists a DC resistance of 90mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
4379-102KS uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 4379-102KS to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 1 µH |
| Tolerance | ±10% |
| Current Rating | 650 mA |
| DC Resistance (DCR) | 90mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.155" L x 0.125" W (3.93mm x 3.17mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Delevan |
| Description | FIXED IND 1UH 650MA 90 MOHM SMD |
| Series | 4379 |
| Product Status | Active |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 106 @ 25MHz |
| Self Resonant Frequency | 175MHz |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.140" (3.56mm) |
