Description
FIXED IND 15UH 2.11A 89 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 4922-15H.
4922-15H has an inductance value of 15 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
4922-15H is rated for 2.11 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
4922-15H lists a DC resistance of 89mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
4922-15H uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 4922-15H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 15 µH |
| Tolerance | ±3% |
| Current Rating | 2.11 A |
| DC Resistance (DCR) | 89mOhm Max |
| Saturation Current | 2.11A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.520" L x 0.250" W (13.21mm x 6.35mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 15UH 2.11A 89 MOHM SMD |
| Series | 4922 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.230" (5.84mm) |
