Description
FIXED IND 680UH 300MA 4.31 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 4922-35J.
4922-35J has an inductance value of 680 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
4922-35J is rated for 300 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
4922-35J lists a DC resistance of 4.31Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
4922-35J uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 4922-35J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 680 µH |
| Tolerance | ±5% |
| Current Rating | 300 mA |
| DC Resistance (DCR) | 4.31Ohm Max |
| Saturation Current | 300mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.520" L x 0.250" W (13.21mm x 6.35mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 680UH 300MA 4.31 OHM |
| Series | 4922 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.230" (5.84mm) |
