Description
FIXED IND 30UH 3.7A 40 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 7447024.
7447024 has an inductance value of 30 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
7447024 is rated for 3.7 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
7447024 lists a DC resistance of 40mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
7447024 uses a package or case of Vertical, No Base, 2 PC Pin. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 7447024 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 30 µH |
| Tolerance | ±20% |
| Current Rating | 3.7 A |
| DC Resistance (DCR) | 40mOhm Max |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.614" Dia x 0.343" W (15.60mm x 8.70mm) |
| Case / Size | Vertical, No Base, 2 PC Pin |
| Package / Case | Vertical, No Base, 2 PC Pin |
| Supplier | Würth Elektronik |
| Description | FIXED IND 30UH 3.7A 40 MOHM TH |
| Series | WE-FI |
| Product Status | Active |
| Type / Construction | Toroidal |
| Core Material | Iron Powder |
| Shielding | Unshielded |
| Inductance Test Frequency | 10 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Vertical, No Base, 2 PC Pin |
| Height - Seated (Max) | 0.343" (8.70mm) |
