Description
FIXED IND 700NH 160MA 1.125 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 7447650270.
7447650270 has an inductance value of 700 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
7447650270 is rated for 160 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
7447650270 lists a DC resistance of 1.125Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
7447650270 uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 7447650270 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 700 nH |
| Tolerance | ±5% |
| Current Rating | 160 mA |
| DC Resistance (DCR) | 1.125Ohm Max |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.039" L x 0.022" W (1.00mm x 0.55mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | Würth Elektronik |
| Description | FIXED IND 700NH 160MA 1.125 OHM |
| Series | WE-RFI |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 11 @ 7.9MHz |
| Self Resonant Frequency | 1.565GHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.026" (0.65mm) |
