CTHC2220F-330K
Central Technologies
- Inductance
- 33 µH
- Current
- 400 mA
- DCR
- 620mOhm Max
- Size
- 0.220" L x 0.197" W (5.60mm x 5.00mm)
Inductor Datasheets
Browse and download PDF datasheets for inductors from leading manufacturers.
Series: CTHC2220F
Browse series tables and compare the available specifications.
CTHC2220F
CTHC2220F-101K
Central Technologies
- Inductance
- 100 µH
- Current
- 250 mA
- DCR
- 1.6Ohm Max
- Size
- 0.220" L x 0.197" W (5.60mm x 5.00mm)
CTHC2220F-221K
Central Technologies
- Inductance
- 220 µH
- Current
- 170 mA
- DCR
- 3.4Ohm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-180K
Central Technologies
- Inductance
- 18 µH
- Current
- 530 mA
- DCR
- 360mOhm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-102J
Central Technologies
- Inductance
- 1 mH
- Current
- 85 mA
- DCR
- 15Ohm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-471J
Central Technologies
- Inductance
- 470 µH
- Current
- 120 mA
- DCR
- 7Ohm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-470J
Central Technologies
- Inductance
- 47 µH
- Current
- 340 mA
- DCR
- 850mOhm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-220K
Central Technologies
- Inductance
- 22 µH
- Current
- 480 mA
- DCR
- 430mOhm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-4R7K
Central Technologies
- Inductance
- 4.7 µH
- Current
- 950 mA
- DCR
- 110mOhm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-680K
Central Technologies
- Inductance
- 68 µH
- Current
- 290 mA
- DCR
- 1.2Ohm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-1R0K
Central Technologies
- Inductance
- 1 µH
- Current
- 1.8 A
- DCR
- 30mOhm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-101J
Central Technologies
- Inductance
- 100 µH
- Current
- 250 mA
- DCR
- 1.6Ohm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-680J
Central Technologies
- Inductance
- 68 µH
- Current
- 290 mA
- DCR
- 1.2Ohm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-102K
Central Technologies
- Inductance
- 1 mH
- Current
- 85 mA
- DCR
- 15Ohm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
CTHC2220F-470K
Central Technologies
- Inductance
- 47 µH
- Current
- 340 mA
- DCR
- 850mOhm Max
- Size
- 0.220 L x 0.197 W (5.60mm x 5.00mm)
| Product | Inductance | Current | DCR | Size | Package | Actions |
|---|---|---|---|---|---|---|
CTHC2220F-330K Central Technologies | 33 µH | 400 mA | 620mOhm Max | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-101K Central Technologies | 100 µH | 250 mA | 1.6Ohm Max | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-221K Central Technologies | 220 µH | 170 mA | 3.4Ohm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-180K Central Technologies | 18 µH | 530 mA | 360mOhm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-102J Central Technologies | 1 mH | 85 mA | 15Ohm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-471J Central Technologies | 470 µH | 120 mA | 7Ohm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-470J Central Technologies | 47 µH | 340 mA | 850mOhm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-220K Central Technologies | 22 µH | 480 mA | 430mOhm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-4R7K Central Technologies | 4.7 µH | 950 mA | 110mOhm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-680K Central Technologies | 68 µH | 290 mA | 1.2Ohm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-1R0K Central Technologies | 1 µH | 1.8 A | 30mOhm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-101J Central Technologies | 100 µH | 250 mA | 1.6Ohm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-680J Central Technologies | 68 µH | 290 mA | 1.2Ohm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-102K Central Technologies | 1 mH | 85 mA | 15Ohm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) | |
CTHC2220F-470K Central Technologies | 47 µH | 340 mA | 850mOhm Max | 0.220 L x 0.197 W (5.60mm x 5.00mm) | 2220 (5750 Metric) |
