MGHC050507U-R10M-LF
Microgate Technology
- Inductance
- 100 nH
- Current
- 31 A
- DCR
- 250mOhm
- Size
- 0.205 L x 0.205 W (5.20mm x 5.20mm)
Inductor Datasheets
Browse and download PDF datasheets for inductors from leading manufacturers.
Series: MGHC050507U
Browse series tables and compare the available specifications.
MGHC050507U
MGHC050507U-R08M-LF
Microgate Technology
- Inductance
- 80 nH
- Current
- 50 A
- DCR
- 250mOhm
- Size
- 0.205 L x 0.205 W (5.20mm x 5.20mm)
MGHC070705U-R15K-LF
Microgate Technology
- Inductance
- 150 nH
- Current
- 32 A
- DCR
- 250mOhm
- Size
- 0.283 L x 0.276 W (7.20mm x 7.00mm)
MGHC070705U-R22K-LF
Microgate Technology
- Inductance
- 220 nH
- Current
- 20 A
- DCR
- 250mOhm
- Size
- 0.283 L x 0.276 W (7.20mm x 7.00mm)
MGHC070705U-R18K-LF
Microgate Technology
- Inductance
- 180 nH
- Current
- 25 A
- DCR
- 250mOhm
- Size
- 0.283 L x 0.276 W (7.20mm x 7.00mm)
| Product | Inductance | Current | DCR | Size | Package | Actions |
|---|---|---|---|---|---|---|
MGHC050507U-R10M-LF Microgate Technology | 100 nH | 31 A | 250mOhm | 0.205 L x 0.205 W (5.20mm x 5.20mm) | - | |
MGHC050507U-R08M-LF Microgate Technology | 80 nH | 50 A | 250mOhm | 0.205 L x 0.205 W (5.20mm x 5.20mm) | - | |
MGHC070705U-R15K-LF Microgate Technology | 150 nH | 32 A | 250mOhm | 0.283 L x 0.276 W (7.20mm x 7.00mm) | - | |
MGHC070705U-R22K-LF Microgate Technology | 220 nH | 20 A | 250mOhm | 0.283 L x 0.276 W (7.20mm x 7.00mm) | - | |
MGHC070705U-R18K-LF Microgate Technology | 180 nH | 25 A | 250mOhm | 0.283 L x 0.276 W (7.20mm x 7.00mm) | - |
