Series: SP54

Browse series tables and compare the available specifications.

SP54

Product Attributes

All Delevan (24873)Pulse Electronics (17770)Bourns Inc. (10998)Gowanda (8081)Taiyo Yuden (8062)TDK (7746)muRata (7717)Abracon (6926)

SP54-100K

CODACA

Inductance: 10 µH
Current: 3.05 A
DCR: 54.5mOhm Max
Size: 0.228 L x 0.205 W (5.80mm x 5.20mm)

SP54-151K

CODACA

Inductance: 150 µH
Current: 0.77 A
DCR: 791mOhm Max
Size: 0.228 L x 0.205 W (5.80mm x 5.20mm)

SP54-102K

CODACA

Inductance: 1000 µH
Current: 0.29 A
DCR: 5.244Ohm Max
Size: 0.228 L x 0.205 W (5.80mm x 5.20mm)

Product	Inductance	Current	DCR	Size	Package	Actions
SP54-100K CODACA	10 µH	3.05 A	54.5mOhm Max	0.228 L x 0.205 W (5.80mm x 5.20mm)	2-SMD	View PDF
SP54-151K CODACA	150 µH	0.77 A	791mOhm Max	0.228 L x 0.205 W (5.80mm x 5.20mm)	2-SMD	View PDF
SP54-102K CODACA	1000 µH	0.29 A	5.244Ohm Max	0.228 L x 0.205 W (5.80mm x 5.20mm)	2-SMD	View PDF
