SPQ105-100M
CODACA
- Inductance
- 10 µH
- Current
- 4.25 A
- DCR
- 30mOhm Max
- Size
- 0.490 L x 0.401 W (10.40mm x 10.20mm)
Inductor Datasheets
Browse and download PDF datasheets for inductors from leading manufacturers.
Series: SPQ105
Browse series tables and compare the available specifications.
SPQ105
SPQ105-181M
CODACA
- Inductance
- 180 µH
- Current
- 1.16 A
- DCR
- 406mOhm Max
- Size
- 0.984 L x 0.819 W (25.00mm x 20.80mm)
SPQ105-471M
CODACA
- Inductance
- 470 µH
- Current
- 0.76 A
- DCR
- 924mOhm Max
- Size
- 0.409 L x 0.402 W (10.40mm x 10.20mm)
| Product | Inductance | Current | DCR | Size | Package | Actions |
|---|---|---|---|---|---|---|
SPQ105-100M CODACA | 10 µH | 4.25 A | 30mOhm Max | 0.490 L x 0.401 W (10.40mm x 10.20mm) | 2-SMD | |
SPQ105-181M CODACA | 180 µH | 1.16 A | 406mOhm Max | 0.984 L x 0.819 W (25.00mm x 20.80mm) | 2-SMD | |
SPQ105-471M CODACA | 470 µH | 0.76 A | 924mOhm Max | 0.409 L x 0.402 W (10.40mm x 10.20mm) | 2-SMD |
