FIXED IND 680NH 16A 5.5 MOHM SMD
| Inductance | 680 nH |
| Tolerance | ±20% |
| Current Rating | 16 A |
| DC Resistance (DCR) | 5.5mOhm Max |
| saturationCurrent | 21A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.287" L x 0.260" W (7.30mm x 6.60mm) |
| Case / Size | 2-SMD, J-Lead |
| Supplier | Abracon |
| Description | FIXED IND 680NH 16A 5.5 MOHM SMD |
| Series | AMPLH7020S |
| productStatus | Active |
| typeConstruction | Molded |
| coreMaterial | Carbonyl Powder |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.079" (2.00mm) |
| features | Low DCR, Soft Saturation |
