Description
FIXED IND 1.5UH 4A 46 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AMRU000404201R5MB1.
AMRU000404201R5MB1 has an inductance value of 1.5 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AMRU000404201R5MB1 is rated for 4 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AMRU000404201R5MB1 lists a DC resistance of 46mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AMRU000404201R5MB1 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AMRU000404201R5MB1 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.5 µH |
| Tolerance | ±20% |
| Current Rating | 4 A |
| DC Resistance (DCR) | 46mOhm Max |
| Saturation Current | 6A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.185" L x 0.165" W (4.70mm x 4.20mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1.5UH 4A 46 MOHM SMD |
| Series | AMRx |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Metal |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.079" (2.00mm) |
