Description
FIXED IND 3.3UH 6.5A 28 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AMRU000606303R3MA1.
AMRU000606303R3MA1 has an inductance value of 3.3 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AMRU000606303R3MA1 is rated for 6.5 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AMRU000606303R3MA1 lists a DC resistance of 28mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AMRU000606303R3MA1 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AMRU000606303R3MA1 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating | 6.5 A |
| DC Resistance (DCR) | 28mOhm Max |
| Saturation Current | 9A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.287" L x 0.268" W (7.30mm x 6.80mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 3.3UH 6.5A 28 MOHM SMD |
| Series | AMRx |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Metal |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.118" (3.00mm) |
