Description
FIXED IND 1MH 150MA 3.4 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for ASPI-0403S-102M-T.
ASPI-0403S-102M-T has an inductance value of 1 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
ASPI-0403S-102M-T is rated for 150 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
ASPI-0403S-102M-T lists a DC resistance of 3.4Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
ASPI-0403S-102M-T uses a package or case of Surface Mount. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from ASPI-0403S-102M-T to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 mH |
| Tolerance | ±20% |
| Current Rating | 150 mA |
| DC Resistance (DCR) | 3.4Ohm Max |
| Operating Temperature | -40°C ~ 85°C |
| Case / Size | Surface Mount |
| Package / Case | Surface Mount |
| Supplier | Abracon |
| Description | FIXED IND 1MH 150MA 3.4 OHM SMD |
| Series | ASPI-0403S |
| Product Status | Active |
| Type / Construction | Wirewound |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Supplier Device Package | Nonstandard |
| Height - Seated (Max) | 0.260" L x 0.175" W (6.60mm x 4.45mm) |
| Features | 0.115" (2.92mm) |
