Description
FIXED IND 47UH 1.7A 270 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for B82144F2473J000.
B82144F2473J000 has an inductance value of 47 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
B82144F2473J000 is rated for 1.7 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
B82144F2473J000 lists a DC resistance of 270mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
B82144F2473J000 uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from B82144F2473J000 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 47 µH |
| Tolerance | ±5% |
| Current Rating | 1.7 A |
| DC Resistance (DCR) | 270mOhm Max |
| Saturation Current | 1.4A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | TDK |
| Description | FIXED IND 47UH 1.7A 270 MOHM TH |
| Series | LBC |
| Product Status | Last Time Buy |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 252kHz |
| Self Resonant Frequency | 7.5MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Through Hole |
