Description
FIXED IND 1MH 150MA 9.5 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for B82442T1105J050.
B82442T1105J050 has an inductance value of 1 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
B82442T1105J050 is rated for 150 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
B82442T1105J050 lists a DC resistance of 9.5Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
B82442T1105J050 uses a package or case of 2220 (5750 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from B82442T1105J050 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 mH |
| Tolerance | ±5% |
| Current Rating | 150 mA |
| DC Resistance (DCR) | 9.5Ohm Max |
| Saturation Current | 310mA |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.220" L x 0.197" W (5.60mm x 5.00mm) |
| Case / Size | 2220 (5750 Metric) |
| Package / Case | 2220 (5750 Metric) |
| Supplier | TDK |
| Description | FIXED IND 1MH 150MA 9.5 OHM SMD |
| Series | B82442T1 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 252kHz |
| Self Resonant Frequency | 1.8MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 252 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 2220 |
| Height - Seated (Max) | 0.209" (5.30mm) |
