Description
FIXED IND 470UH 240MA 4.73 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for B82442T1474J050.
B82442T1474J050 has an inductance value of 470 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
B82442T1474J050 is rated for 240 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
B82442T1474J050 lists a DC resistance of 4.73Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
B82442T1474J050 uses a package or case of 2220 (5750 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from B82442T1474J050 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 470 µH |
| Tolerance | ±5% |
| Current Rating | 240 mA |
| DC Resistance (DCR) | 4.73Ohm Max |
| Saturation Current | 460mA |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.220" L x 0.197" W (5.60mm x 5.00mm) |
| Case / Size | 2220 (5750 Metric) |
| Package / Case | 2220 (5750 Metric) |
| Supplier | TDK |
| Description | FIXED IND 470UH 240MA 4.73 OHM |
| Series | B82442T1 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 20 @ 796kHz |
| Self Resonant Frequency | 2.6MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 796 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 2220 |
| Height - Seated (Max) | 0.209" (5.30mm) |
