FIXED IND 2.7UH 10.5A 9.3 MOHM
| Inductance | 2.7 µH |
| Tolerance | ±30% |
| Current Rating | 10.5 A |
| DC Resistance (DCR) | 9.3mOhm Max |
| saturationCurrent | 13A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 2.7UH 10.5A 9.3 MOHM |
| Series | BPCI |
| productStatus | Active |
| typeConstruction | Multilayer |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.236" (6.00mm) |
| features | - |
