Description
FIXED IND 1.7NH 680MA 110 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BSCQ000603031N7B00.
BSCQ000603031N7B00 has an inductance value of 1.7 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BSCQ000603031N7B00 is rated for 680 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BSCQ000603031N7B00 lists a DC resistance of 110mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BSCQ000603031N7B00 uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BSCQ000603031N7B00 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.7 nH |
| Tolerance | ±0.1nH |
| Current Rating | 680 mA |
| DC Resistance (DCR) | 110mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1.7NH 680MA 110 MOHM |
| Series | BSCQ |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 14 @ 500MHz |
| Self Resonant Frequency | 10GHz |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 |
| Height - Seated (Max) | 0.013" (0.33mm) |
