Description
FIXED IND 23NH 610MA 190 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for C0603C-23N0J1Y.
C0603C-23N0J1Y has an inductance value of 23 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
C0603C-23N0J1Y is rated for 610 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
C0603C-23N0J1Y lists a DC resistance of 190mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
C0603C-23N0J1Y uses a package or case of Surface Mount. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from C0603C-23N0J1Y to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 23 nH |
| Tolerance | ±5% |
| Current Rating | 610 mA |
| DC Resistance (DCR) | 190mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 603 |
| Case / Size | Surface Mount |
| Package / Case | Surface Mount |
| Supplier | Delevan |
| Description | FIXED IND 23NH 610MA 190 MOHM |
| Series | C0603 |
| Product Status | Obsolete |
| Type / Construction | Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 35 @ 250MHz |
| Self Resonant Frequency | 2.85GHz |
| Inductance Test Frequency | 250 MHz |
| Supplier Device Package | 0603 (1608 Metric) |
| Height - Seated (Max) | 0.071" L x 0.047" W (1.80mm x 1.20mm) |
| Features | 0.040" (1.02mm) |
