Description
FIXED IND 2.2UH 1.2 OHM SMD
Specifications
Inductance
2.2 µH
Current Rating
500 mA Max
DC Resistance (DCR)
1.2Ohm
Parameter Guide
Understand the key electrical and mechanical specifications for CT0603LSF-222J.
Inductance
2.2 µH
CT0603LSF-222J has an inductance value of 2.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
500 mA Max
CT0603LSF-222J is rated for 500 mA Max. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
1.2Ohm
CT0603LSF-222J lists a DC resistance of 1.2Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from CT0603LSF-222J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 2.2 µH |
| Tolerance | ±5% |
| Current Rating | 500 mA Max |
| DC Resistance (DCR) | 1.2Ohm |
| Operating Temperature | -40°C ~ 85°C |
| Supplier | Central Technologies |
| Description | FIXED IND 2.2UH 1.2 OHM SMD |
| Series | ct0603lsf |
| Product Status | Active |
| Type / Construction | Wirewound |
| Self Resonant Frequency | 150MHz |
| Mounting Type | Surface Mount |
