Description
FIXED IND 330UH 4 OHM TH
Specifications
Inductance
330 µH
Current Rating
200 mA
DC Resistance (DCR)
4Ohm
Parameter Guide
Understand the key electrical and mechanical specifications for CT187LYF-331J.
Inductance
330 µH
CT187LYF-331J has an inductance value of 330 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
200 mA
CT187LYF-331J is rated for 200 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
4Ohm
CT187LYF-331J lists a DC resistance of 4Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from CT187LYF-331J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 330 µH |
| Tolerance | ±5% |
| Current Rating | 200 mA |
| DC Resistance (DCR) | 4Ohm |
| Operating Temperature | -55°C ~ 125°C |
| Supplier | Central Technologies |
| Description | FIXED IND 330UH 4 OHM TH |
| Series | ct187lyf |
| Product Status | Active |
| Q @ Frequency | 80 Min @ 796 kHz |
| Self Resonant Frequency | 2.3MHz |
| Inductance Test Frequency | 796 kHz |
| Mounting Type | Through Hole |
