Description
FIXED IND 68UH 520 MOHM SMD
Specifications
Inductance
68 µH
Current Rating
0.50 A
DC Resistance (DCR)
520mOhm
Parameter Guide
Understand the key electrical and mechanical specifications for CT636CYF-680M.
Inductance
68 µH
CT636CYF-680M has an inductance value of 68 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
0.50 A
CT636CYF-680M is rated for 0.50 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
520mOhm
CT636CYF-680M lists a DC resistance of 520mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from CT636CYF-680M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 68 µH |
| Tolerance | ±20% |
| Current Rating | 0.50 A |
| DC Resistance (DCR) | 520mOhm |
| Operating Temperature | -30°C ~ 100°C |
| Supplier | Central Technologies |
| Description | FIXED IND 68UH 520 MOHM SMD |
| Series | ct636cyf |
| Product Status | Active |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
