Description
FIXED IND 82NH 51.5 MOHM SMD
Specifications
Inductance
82 nH
Current Rating
320 mA Max
DC Resistance (DCR)
51.5mOhm
Parameter Guide
Understand the key electrical and mechanical specifications for CTAC1008F-82NK.
Inductance
82 nH
CTAC1008F-82NK has an inductance value of 82 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
320 mA Max
CTAC1008F-82NK is rated for 320 mA Max. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
51.5mOhm
CTAC1008F-82NK lists a DC resistance of 51.5mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from CTAC1008F-82NK to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 82 nH |
| Tolerance | ±10% |
| Current Rating | 320 mA Max |
| DC Resistance (DCR) | 51.5mOhm |
| Operating Temperature | -25°C ~ 85°C |
| Supplier | Central Technologies |
| Description | FIXED IND 82NH 51.5 MOHM SMD |
| Series | ctac1008f |
| Product Status | Active |
| Type / Construction | Wirewound |
| Self Resonant Frequency | 1GHz |
| Mounting Type | Surface Mount |
