Description
FIXED IND 1UH 70 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTC5F-1R0K.
CTC5F-1R0K has an inductance value of 1 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTC5F-1R0K is rated for -. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTC5F-1R0K lists a DC resistance of 70mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTC5F-1R0K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTC5F-1R0K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 µH |
| Tolerance | ±10% |
| Current Rating | - |
| DC Resistance (DCR) | 70mOhm Max |
| Saturation Current | 1.9A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.175 Dia x 0.375 L (4.44mm x 9.52mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Central Technologies |
| Description | FIXED IND 1UH 70 MOHM TH |
| Series | CTC5F |
| Product Status | Active |
| Type / Construction | - |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | 47 @ 7.9MHz |
| Self Resonant Frequency | 140MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
| Height - Seated (Max) | - |
| Features | - |
