Description
FIXED IND 5.6UH 100.9 MOHM SMD
Specifications
Inductance
5.6 µH
DC Resistance (DCR)
100.9mOhm Max
Dimensions
0.185 L x 0.185 W (4.70mm x 4.70mm)
Parameter Guide
Understand the key electrical and mechanical specifications for CTCDRH4D28F-5R6N.
Inductance
5.6 µH
CTCDRH4D28F-5R6N has an inductance value of 5.6 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
DC Resistance (DCR)
100.9mOhm Max
CTCDRH4D28F-5R6N lists a DC resistance of 100.9mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Package / Case
Nonstandard
CTCDRH4D28F-5R6N uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTCDRH4D28F-5R6N to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 5.6 µH |
| Tolerance | ±30% |
| DC Resistance (DCR) | 100.9mOhm Max |
| Saturation Current | 1.17A |
| Operating Temperature | -30°C ~ 100°C |
| Dimensions | 0.185 L x 0.185 W (4.70mm x 4.70mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Central Technologies |
| Description | FIXED IND 5.6UH 100.9 MOHM SMD |
| Series | CTCDRH4D28F |
| Product Status | Active |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.118 (3.00mm) |
