Description
FIXED IND 470UH 1.34 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTCH875F-471K.
CTCH875F-471K has an inductance value of 470 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTCH875F-471K is rated for -. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTCH875F-471K lists a DC resistance of 1.34Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTCH875F-471K uses a package or case of Radial, Vertical Cylinder. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTCH875F-471K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 470 µH |
| Tolerance | ±10% |
| Current Rating | - |
| DC Resistance (DCR) | 1.34Ohm Max |
| Saturation Current | 410mA |
| Operating Temperature | -30°C ~ 100°C |
| Dimensions | 0.307 Dia (7.80mm) |
| Case / Size | Radial, Vertical Cylinder |
| Package / Case | Radial, Vertical Cylinder |
| Supplier | Central Technologies |
| Description | FIXED IND 470UH 1.34 OHM TH |
| Series | CTCH875F |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Radial |
| Height - Seated (Max) | 0.295 (7.50mm) |
| Features | - |
