Description
FIXED IND 1MH 210MA 8.6 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTFCF-102K.
CTFCF-102K has an inductance value of 1 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTFCF-102K is rated for 210 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTFCF-102K lists a DC resistance of 8.6Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTFCF-102K uses a package or case of Radial, Vertical Cylinder. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTFCF-102K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 mH |
| Tolerance | ±10% |
| Current Rating | 210 mA |
| DC Resistance (DCR) | 8.6Ohm Max |
| Saturation Current | - |
| Operating Temperature | -20°C ~ 100°C |
| Dimensions | 1.500 Dia (38.10mm) |
| Case / Size | Radial, Vertical Cylinder |
| Package / Case | Radial, Vertical Cylinder |
| Supplier | Central Technologies |
| Description | FIXED IND 1MH 210MA 8.6 OHM TH |
| Series | CTFCF |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | 70 @ 250kHz |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 250 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Radial |
| Height - Seated (Max) | 1.031 (26.20mm) |
| Features | - |
