Description
FIXED IND 68UH 800MA 140 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTH7F-680K.
CTH7F-680K has an inductance value of 68 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTH7F-680K is rated for 800 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTH7F-680K lists a DC resistance of 140mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTH7F-680K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTH7F-680K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 68 µH |
| Tolerance | ±10% |
| Current Rating | 800 mA |
| DC Resistance (DCR) | 140mOhm Max |
| Saturation Current | 1.5A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.290 Dia x 0.602 L (7.37mm x 15.30mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Central Technologies |
| Description | FIXED IND 68UH 800MA 140 MOHM TH |
| Series | CTH7F |
| Product Status | Active |
| Shielding | Unshielded |
| Self Resonant Frequency | 7MHz |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
